Bottom Seal Flying Knife Bottom Seal

Bottom Seal Bag Making Machine

BS 500 Delta / BS 600 Delta / BS 800 Delta

Bottom Seal Bag Making Machine

BS 500 Delta / BS 600 Delta / BS 800 Delta

When you consider bottom seal bag making machines, we’ve got a huge variety for you to choose from. If you are looking for a High Speed Bottom Seal machine, which is suitable for LDPE, HDPE and PP Film, then go for BS 500 Delta or BS 600 Delta or BS 800 Delta. You can also opt for the most commonly used machine such as DD 800 Delta or DD 250 Delta.

Features

This is a high speed bottom seal bag making machine uses a tubular roll of different sizes to make regular bottom seal bags and with other various attachments. LDPE , HDPE , PP materials can be used on this machine.

There are various models differentiated by Web width which one can select as per ones requirement.

  • High Speed up to 200 strokes/min.
  • Servo Motor for indexing and Accuracy
  • Microprocessor Controlled with Digital Display
  • Keyboard Setting for Speed, Size & Count
  • Backlit Display for Operating Parameters
  • Tension free Web for Strong Sealing
  • Photocell Control to convert Printed Rolls
Attachments

The following optional attachments / tools are available to add features to the machine and make variety of bag structures:

  • Handle Punch
  • Hole Punch bank
  • Twin seal with handle punch
  • Twin sealer for vest type bags
  • K-seal attachment
  • Double line or single line sealing type
download brochure
TYPES OF BAGS THAT CAN BE MADE
Specifications
Model Max.Web Draw Length mm Max. Speed Connected Approx Dimension
With mm Max Strokes/min Load KW Weight Kg WxLxH cms
BS 500 Delta 460 700 200 6.0 1150 125x278x137
BS 600 Delta 580 900 170 6.5 1300 137x278x137
BS 800 Delta 780 900 150 7.0 1400 157x278x137
